VEMAG

Sausage production line VEMAG

VEMAG vacuum stuffer

Type: ROBOT HP 10C
Hopper capacity: 250 l
Productivity: 4000-5000 kg/h
External dimensions: 2100 x 1350 x 2150 mm
Filling pressure: max. 40 bar
Maximum serving size: 0- 10000
Vacuum pump: 20m3/h
Total power: 9.5 kW
Hydraulic pump power: 7.5 kW
Filling speed adjustable: 0 - 100%

Device for automatic unscrewing and portioning to length

Type: LPG 208
Power: 6.0 KW
External dimensions: 1650 x 1000 x 1350 mm
For sausages with a caliber of 13 to 40 mm
For sausages with a length from 20 mm to approx. 400 mm
Portioning speed: over 2000 ports/min. (depending on the weight of the portion, serving)
length and housing type used)

VEMAG sausages hanger

Type: AH 204
External dimensions: 3250 x 850 x 1700 mm
Maximum hook feed: 200/min
Nominal power, total: 1.5 KW

Ask about product
